Description
| Model | |
| Model | ZEB-N4A1H1-2MP |
| System | |
| Main Processor | ARM Cortex A9 Processor(HI3520D) |
| Operating System | Embedded LINUX |
| Video | |
| Input | 4CH (1920×1080, 1280×960, 1280×720, etc), Incoming Bandwidth:24MB |
| Video Output | 1 VGA, 1 HDMI |
| Audio | |
| Input | 1 Port RCA |
| Output | 1 Port RCA |
| Alarm | |
| Sensor Input | No |
| Output | No |
| Motion Detection | 4 Channel |
| Email Alarm | Support |
| Display | |
| HDMI Resolution | Resolution : 1080P(1920×1080) 720P:(1280×720) |
| VGA | Resolution : 800×600, 1024×768, 1280×720, 1280×1024, 1920×1080 |
| Display Split | 4 Channel / 1Channel |
| Digital Zoom | No |
| OSD | Camera Title, Time, Video Loss, Recording, Motion Detection |
| Recording | |
| Video Compression | H.264 |
| Resolution | 4CH×1080P/4CHx960P/4CH×720P, etc |
| Record Rate | PAL :1080P@100fps, 960P@100fps, 720P@100fps, D1@100fps NTSC:1080P@120fps, 960P@120fps, 720P@120fps, D1@120fps |
| Record Mode | Manual\Timer\Motion Detection |
| Playback & Backup | |
| Local Sync Playback | 1CH@1080P |
| Decode Capability | 1CH 1080P@30fps |
| Remote Sync Playback | YES |
| Search Mode | ALL, Channel, Time, Date, Motion Detection |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play |
| Backup Mode | USB Device/Network |
| Network | |
| Interface | 1 RJ45 10M/100M Adaptive Ethernet Interface |
| Network Functions | HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, IP Search, P2P |
| Onvif function | Support Onvif 2.4 |
| Web Browser | IE6-11, Google Chrome (IE Tab), Firefox (IE Tab) |
| CMS Software | Support Windows 7/ Windows 8/Windows 10 |
| Cloud Support (P2P) | Yes |
| Smartphone | iPhone, iPad, Android, Android PAD |
| Hard Disk Drive | |
| Interface Type | 1 SATA Interface |
| Capacity | Up to 6TB capacity |
| General | |
| Languages | Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek |
| USB Interfaces | 2 USB 2.0 Interfaces |
| Power Supply | DC12V/2A |
| Working Environment | -10~55℃/10~90% |
| Dimension (W×D×H) | 260*215*43 (mm) |
| Weight | 2.0KG (without HDD) |
