Description

Camera
Image Sensor
2 MP CMOS
Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
PAL: 1/25 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s
Day & Night
ICR
Angle Adjustment
Pan: 0° to 360°,Tilt: 0° to 90°,Rotate: 0° to 360°
Signal System
PAL/NTSC
Lens
Lens Type
2.8 mm, 3.6 mm fixed lens
Focal Length & FOV
2.8 mm, horizontal FOV: 101°, vertical FOV: 55°, diagonal FOV: 122°;

3.6 mm, horizontal FOV: 84°, vertical FOV: 47°, diagonal FOV: 99°

Lens Mount
M12
Microphone
Pickup Distance
In a radius of up to 5 m
Amount
1
Speaker
Rated Power
2 W
Speaker Range
In a radius of up to 5 m
Illuminator
Supplement Light Type
Smart,IR,White Light
Supplement Light Range
IR: Up to 25 m,White Light: Up to 20 m
Image Settings
Anti-banding,

Brightness,

Sharpness,

Smart IR

Frame Rate
TVI: 1080p @25 fps/30 fps
Day/Night Mode
Auto/Color
Wide Dynamic Range (WDR)
Digital WDR
Image Enhancement
DWDR,

BLC,

HLC,

Global

Noise Reduction
3D DNR
White Balance
Auto,

Manual

Audio
Audio Function
Echo Cancellation, AI Noise Reduction, Automatic Gain Control
Interface
Video Output
1 HD analog output
Alarm
Flashing Light Alarm (Red & Blue)
General
Power
12 VDC ± 25%, max.6.2 W,*You are recommended to use one power adapter to supply the power for one camera.
Material
Plastic
Dimension
179 mm × 66 mm × 69.1 mm (7.1″ × 2.6″ × 2.7″)
Approx. 260 g (0.6 lb.)
Operating Condition
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
Communication
HIKVISION-C
Language
English
Approval
Protection
IP67
