Description
Product Description
|
Product Name
|
4 inch Thermal Label Barcode Printer
|
|
Print Method
|
Direct thermal
|
|
Emulation
|
TSPL2、EPL、ZPL、DPL
|
|
Paper Type
|
Stack or Roll type paper
|
|
Paper Width
|
37-120mm
|
|
Effective Printing Width
|
37-108mm (108mm max)
|
|
Max Height
|
1770mm
|
|
Paper Thickness
|
0.05mm-0.26mm
|
|
Label Type
|
Continuous, gap, black mark, fan-fold, punched hole, label paper, tag
|
|
Paper Roll Diameter
|
8 inch roll-type or foldable thermal label paper
|
|
Interface
|
USB2.0(Standard USB)/Bluetooth optional)
|
|
Resolution
|
203 dpi(Speed=6.0inch)
|
|
Memory
|
8MB Flash Memory/8MB SDRAM
|
|
Rotation
|
0°、90°、180°、270°
|
|
Speed
|
6.0 inch/Sec (152mm/s)
|
|
Barcode
|
1D+2D barcode
|
|
TPH Working Life
|
Over 100,000,000 pulses or over 50 km
|
|
Driver
|
（1）Windows：XP、7、8、10 （32-bit and 64-bit systems included）；
（2）Mac：v10.6.8、v10.7.x、v10.8.x、v10.9.x、10.10.x、10.11.x etc； （3）Linux：centos 7.0 X64、ubuntu 12.04 X86 and X64 version； |
| WEIGHT | 3.5 kg |
|---|---|
| DIMENSIONS | 28 × 18 × 18 cm |
| INTERFACE | USB, Bluetooth+USB |
| Printing Features | |
| Resolution | 203 DPI |
| Print method | Direct Thermal |
| Max. print speed | 152 mm(6”)/s Max. |
| Max.print width | 108 mm (4.25″) |
| Max. print length | 1778 mm (70″) |
| Media | |
| Media type | Continuous, gap, black mark, fan-fold and punched hole |
| Media width | 32~118mm (1.0”-4.6”) |
| Media thickness | 0.06 ~ 0.25 mm (2.36 ~ 9.8 mil) |
| Media core diameter | 25.4 ~ 76.2 mm (1 “~ 3 “) |
| Label length | 10 ~ 1778 mm (0.39 ” ~ 70 “) |
| Label roll capacity | 127 mm (5“) (External diameter) |
| Performance Features | |
| Processor | 32-bit CPU |
| Memory | 8MB Flash Memory/ 8MB SDRAM |
| Interface | Standard: USB, Bluetooth (Optional) |
| Fonts/Graphics/Symbologies | |
| Internal fonts | 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. |
| 1D barcode | Code 39, Code 93, Code 128UCC, Code 128 ，subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on,MSI, PLESSEY, POSTNET, China POST |
| 2D barcode | PDF-417, Maxicode, DataMatrix, QR code |
| Rotation | 0°、90°、180°、270° |
| Emulaion | TSPL、EPL |
